User signin/signup using Phone number, Otp in MERN stack

After creating node app using express generator we will use jwt auth for token and msg91 . We will register as startup and get free credentials for send otp

Our backend Node app folder stracture

1bin
2controllers
3models
4modules
5node_modules
6public
7views
8app.js
9package.json
10package-lock.json

Install mongoose to connect database with you app

1npm i mongoose --save

In your app.js

1var  createError = require("http-errors");
2var  express = require("express");
3var  path = require("path");
4var  cookieParser = require("cookie-parser");
5var  logger = require("morgan");
6const  bodyParser = require("body-parser");
7var  mongoose = require("mongoose");
8var  app = express();
9
10//setup your mongo database address here
11var  mongoServer = "mongodb+srv://***********************.mongodb.net/test?retryWrites=true&w=majority";
12
13// connect your mongo
14mongoose.connect(
15    mongoServer,
16    {
17    useNewUrlParser:  true,
18    useUnifiedTopology:  true,
19    useFindAndModify:  false,
20    useCreateIndex:  true
21    },
22    err  => {
23    console.log(err ? err : "mongodb connected");
24    }
25);
26
27// view engine setup
28app.set("views", path.join(__dirname, "views"));
29app.set("view engine", "ejs");
30
31// routes
32var  usersRouter = require("./routes/users");
33
34// middleware
35app.use(logger("dev"));
36app.use(express.json());
37app.use(express.urlencoded({ extended:  false }));
38app.use(cookieParser());
39app.use(bodyParser.urlencoded({ extended:  false }));
40app.use(bodyParser.json());
41app.use(express.static(path.join(__dirname, "public")));
42
43// routes middleware
44app.use("/api/v1/users", usersRouter);
45
46// catch 404 and forward to error handler
47app.use(function(req, res, next) {
48    next(createError(404));
49});
50
51// error handler
52app.use(function(err, req, res, next) {
53    // set locals, only providing error in development
54    res.locals.message = err.message;
55    res.locals.error = req.app.get("env") === "development" ? err : {};
56
57    // render the error page
58    res.status(err.status || 500);
59    res.json({ err });
60});
61
62module.exports = app;

Create a user model inside models/user.js Take user name and phone number where phone number should be unique Inside models/user.js

1var  mongoose = require("mongoose");
2var  Schema = mongoose.Schema;
3
4var  userSchema = new  Schema(
5    {
6        name: {
7            type:  String
8        },
9        phoneNumber: {
10            type:  Number,
11            unique:  true,
12            required:  true
13        },
14    },
15    { timestamps:  true }
16);
17
18module.exports = mongoose.model("User", userSchema);

Before working on our user controller install these packages

Install jsonwebtoken to use jwt token for user auth

1npm i jsonwebtoken --save

Install Msg91 sendotp package to handle send/verify otp

1npm i sendotp --save

After installing these packages, your package.json look like

1{
2    "name": "backend",
3    "version": "0.0.0",
4    "private": true,
5    "scripts": {
6        "start": "node ./bin/www"
7    },
8    "dependencies": {
9        "body-parser": "^1.19.0",
10        "cookie-parser": "~1.4.4",
11        "debug": "~2.6.9",
12        "ejs": "~2.6.1",
13        "express": "~4.16.1",
14        "http-errors": "~1.6.3",
15        "jsonwebtoken": "^8.5.1",
16        "mongoose": "^5.9.1",
17        "morgan": "~1.9.1",
18        "sendotp": "^1.2.9"
19    }
20}

Let’s go to our controllers/userController.js

Make methods or actions inside controllers/userController.js to handle all the logic for signin, signup, sendotp, verifyotp

Below SENDOTP method recieves the user phone number sends a otp to the phone number

Below VERIFYOTP method is to verify entered otp matched with sendotp, if otp matches then we will check whether the user exist in the database or not. If user exists then we will do successfull signin otherwise we will do successfull signup. If entered otp not matched then we will send error message. Pass your Msg91 OTP credintial and SENDERID ( you will get these in the Msg91 dashboard) to userController.js

This all things happens inside controllers/userController.js

1var  User = require("../models/user");
2var  jwt = require("jsonwebtoken");
3const  SendOtp = require("sendotp");
4
5// pass your msg91 otp creditials SendOtp
6const  sendOtp = new  SendOtp("****otpcredentials****");
7
8// send otp for sending otp to entered phone number and also pass message sender name like app name from your credintials
9const SENDOTP = (req,res) => {
10    sendOtp.send(req.body.phoneNumber, "***senderID***", (err, data) => {
11        if (err) return  res.json({ err });
12        data.type == "success"
13        ? res.json({ success:  true })
14        : res.json({ success:  false });
15    });
16}
17
18// verify otp to verify entered otp matched with sentotp or not
19const VERIFYOTP = (res,res) => {
20    sendOtp.verify(req.body.phoneNumber, req.body.otp, function(err, data) {
21        if (err) return  res.json({ err });
22        if (data.type == "success") {
23            let { phoneNumber } = req.body;
24            User.findOne({ phoneNumber }, (err, user) => {
25                if (err) return  res.json({ err });
26                if (!user) {
27                    // user signup
28                    User.create(req.body, (err, user) => {
29                        if (err) return  res.json({ err });
30                        jwt.sign(
31                            {
32                                userId:  user._id,
33                                phoneNumber:  user.phoneNumber
34                            },
35                            "thisissecret",
36                            (err, signuptoken) => {
37                                if (err) return  res.json({ err });
38                                res.json({
39                                    success:  true,
40                                    signuptoken,
41                                    userId:  user._id,
42                                    message:  "registered successfully"
43                                });
44                            }
45                        );
46                    });
47                }
48                if (user) {
49                    // user signin
50                    jwt.sign(
51                        {
52                            userId:  user._id,
53                            phoneNumber:  user.phoneNumber
54                        },
55                        "thisissecret",
56                        (err, logintoken) => {
57                            if (err) return  res.json({ err });
58                            res.json({ logintoken, userId:  user._id });
59                        }
60                    );
61                }
62            });
63        }
64        if (data.type == "error") res.json({ success:  false, message:  data.message });
65    });
66}
67module.exports = { SENDOTP, VERIFYOTP }

Inside routes/users.js

1var  express = require("express");
2var  userController = require("../controllers/userController");
3var  userauth = require("../modules/userAuth");
4var  router = express.Router();
5
6// send otp
7router.post("/sendotp", userController.SENDOTP);
8
9// verify otp
10router.post("/verifyotp", userController.VERIFYOTP);
11
12module.exports = router;

Now let’s handle your frontend React.js

Make component Auth.jsx inside src folder to handle user signup/signin based on the phone number

Install validator npm package to check whether the entered phone number is valid or not

1npm i validator --save

Here in the Auth.jsx we are handling both phone number and otp entry pages.

Before doing the fetch request, add a proxy to React package.json file for our backend. our backend runs on 3000 so, add this "proxy": "http://localhost:3000" to package.json In React

Inside your src/Auth.jsx

1import  React  from  'react';
2import  validator  from  'validator';
3import { NavLink, withRouter } from  'react-router-dom';
4
5class  Auth  extends  React.Component {
6    constructor() {
7        super();
8        this.state = {
9            dispalyPhonePage:  true,
10            phoneNumber:  '',
11            otp:  '',
12            invalid:  '',
13            msg:  ''
14        };
15    }
16
17    handleChange = event  => {
18        this.setState({ invalid:  '', msg:  '' });
19        let { name, value } = event.target;
20        this.setState({ [name]:  value });
21    };
22
23    editPhoneNo = () => {
24        this.setState({ dispalyPhonePage:  true });
25    };
26
27    handleSendOtp = () => {
28        this.setState({ dispalyPhonePage:  false });
29        fetch('/api/v1/users/sendotp',
30            {
31                method:  'POST',
32                headers: {
33                    'Content-Type':  'application/json'
34                },
35                body:  JSON.stringify({
36                    phoneNumber:  this.state.phoneNumber
37                })
38            }
39        )
40        .then(res  =>  res.json())
41        .then(data  => {
42            if (data.success) {
43                this.setState({ dispalyPhonePage:  false });
44            } else {
45                this.setState({ dispalyPhonePage:  true });
46            }
47        });
48    };
49
50    submitPhoneNo = e  => {
51        e.preventDefault();
52        if(this.state.phoneNumber) {
53            validator.isMobilePhone(this.state.phoneNumber)
54                ? this.handleSendOtp()
55                : this.setState({ invalid:  'Enter a valid Phone Number' })
56        }
57        else {
58            this.setState({ msg:  "Phone Number can't be empty" });
59        }
60    };
61
62    handleVerifyOtp = e  => {
63        e.preventDefault();
64        if(this.state.otp){
65            fetch('/api/v1/users/verifyotp',
66                {
67                    method:  'POST',
68                    headers: {
69                        'Content-Type':  'application/json'
70                    },
71                    body:  JSON.stringify({
72                        phoneNumber:  this.state.phoneNumber,
73                        otp:  this.state.otp
74                    })
75                }
76            )
77            .then(res  =>  res.json())
78            .then(data  => {
79                if (data.success) {
80                    localStorage.setItem('storiesloggeduser', data.signuptoken);
81                    localStorage.setItem('storiesloggeduserid', data.userId);
82                    this.props.handleIslogged(true);
83                    this.props.history.push('/');
84                }
85                if (!data.success) this.setState({ msg:  data.message });
86                if (data.logintoken) {
87                    localStorage.setItem('storiesloggeduser', data.logintoken);
88                    localStorage.setItem('storiesloggeduserid', data.userId);
89                    this.props.handleIslogged(true);
90                    this.props.history.push('/');
91                }
92            })
93        }
94        else {
95            this.setState({ msg:  "OTP can't be empty" })
96        }
97    };
98
99    displayPhonePage = () => {
100        return (
101            <form onSubmit={this.submitPhoneNo}>
102                <label>{this.state.invalid}</label>
103                <label>{this.state.msg}</label>
104                <label>Enter a phone number</label>
105                <input
106                    type="tel"
107                    name="phoneNumber"
108                    placeholder="8888888888"
109                    value={this.state.phoneNumber}
110                    onChange={this.handleChange}
111                    required
112                />
113                <input type="submit"  value="NEXT"/>
114            </form>
115        )
116    }
117
118    displayOtpPage = () => {
119        return (
120            <form onSubmit={this.handleVerifyOtp}>
121                <label>{this.state.invalid}</label>
122                <label>{this.state.msg}</label>
123                <label>Enter OTP</label>
124                <input
125                    type="tel"
126                    name="otp"
127                    placeholder="8432"
128                    value={this.state.otp}
129                    onChange={this.handleChange}
130                    required
131                />
132                <div>
133                    <button onClick={this.editPhoneNo}>Edit Phone Number </button>
134                    <button onClick={this.handleSendOtp}> Resend OTP </button>
135                </div>
136                <input type="submit"  value="NEXT"/>
137            </form>
138        )
139    }
140
141    render() {
142        let { dispalyPhonePage } = this.state;
143        return(
144            <>
145                {dispalyPhonePage ? this.displayPhonePage() : this.displayOtpPage()}
146            </>
147        )
148    }
149}
150export  default  withRouter(Auth);

I hope above document helps in better understanding of basic work flow of user signin/signup using phone number and otp in Mern stack

Thank You

Chaduvula Prasanth

User signin/signup using Phone number, Otp in MERN stack

User signin/signup using Phone number, Otp in MERN stack

More articles from Chaduvula Prasanth

Detailed understanding of rails and it's workflow

Thinking in React
